| Attribute | Value |
|---|---|
| Brand | MADISON |
| Product Type | Float Level Sensor |
| Body Material | 316 Stainless Steel |
| Accuracy | +/-0.25 in |
| Connection Size | 1-1/2 in |
| Connection Type | NPT |
| Mounting Direction | Vertical |
| Max. Operating Pressure | 100 psi |
| Nameplate Voltage | 12/30V DC |
| Probe Material | 316 Stainless Steel |
| Max. Media Temperature | 221 °F |
| Float Diameter | 1-1/2 in |
| Float Length | 2 in |
| Stem Length | 18-5/8 in |
| Stem Material | 316 Stainless Steel |
| Standards | CE; cULus |
| Overall Length | 20.9 in |
| Manufacturer Part Number | C4651-12802 |
| Enclosure Rating | Not Rated |
| Float Material | Polypropylene |
| Output Voltage Range | 4 to 20mA |
| Max. Specific Gravity | 0.7 |
| Number of Analog Outputs | 1 |
| Output Wire Configuration | 2-Wire |
| Probe Type | Rod |
| For Media Type | Chemicals; Nonhazardous Liquids |
| Range | 16 in |
| Process Connection | 1-1/2 in NPT |
| UNSPSC | 41111938 |
| Country of Origin | USA (subject to change) |
